AMERICAN DRYER® ADA-W Recess Kit (Wall Box + Face Plate) - Stainless Steel with White Epoxy (HAND DRYER NOT INCLUDED)

AMERICAN DRYER® ADA-W Recess Kit - "Closed Style" White Epoxy on Steel ADA Wall Box + Face Plate for Use with the All AMERICAN DRYER® GX1, AD90, EXT7, GXT9, & CPC9 Series Hand Dryers (now by WORLD DRYER®)

ARE YOU A CONTRACTOR? CALL (210) 794-7450 FOR VOLUME DISCOUNTS!

PLEASE NOTE: An AMERICAN DRYER® Hand Dryer is Not Included, but may be purchased separately

American Dryer ADA-W Recess Kit Overview

The American Dryer ADA-W Recess Kit gives your hand dryer a clean, built-in look. Instead of mounting the dryer on the wall surface, this kit lets it sit flush inside the wall. The result is a neat, professional finish that works great in busy commercial restrooms.

This kit includes a stainless-steel wall box and a face plate with a white epoxy finish. The white epoxy stainless steel recess kit is built to handle daily use in high-traffic areas. The hand dryer is not included.

Compatible American Dryer Models

This American Dryer recessed mounting kit is compatible with these specific models from the American Dryer Hand Dryers lineup:

• GX Series

• GXT9

• EXT9

• CPC9

• AD90

Make sure your dryer is one of these before you buy the American Dryer ADA-W Recess Kit.

DIMENSIONS:

• WALL BOX: 9-7/8" (251 mm) High 12-3/16" (310 mm) Wide x 2" (51 mm) Deep
• FACE PLATE / TRIM PIECE (Outer Dimensions): 11-7/8" (302 mm) High x 12-3/4" (324 mm) Wide

Features & Benefits

• Flush wall installation keeps restrooms looking clean and open

• White epoxy finish matches most restroom decor and resists rust and wear

• Stainless steel construction means it holds up in commercial settings

• ADA-compliant design helps meet accessibility requirements

• Includes both the wall box and face plate

Product Specifications

• Finish: White Epoxy on Stainless Steel

• Includes: Wall Box and Face Plate

• Hand Dryer: Not Included

• Compatible with: GX, GXT9, EXT9, CPC9, AD90

Shipping, Returns & Warranty

Most orders ship fast. Check our shipping policy for details on delivery times and costs. If something is not right, our returns page has everything you need to know. Warranty coverage follows American Dryer's standard terms.

Why Buy from Allied Hand Dryer

We carry a wide range of hand dryer accessories and commercial hand dryer recess kits. Our team knows these products well and can help you pick the right fit. You get genuine parts, honest pricing, and support when you need it.

FAQs

What is the American Dryer ADA-W Recess Kit used for?

It lets you install a compatible American Dryer hand dryer inside the wall for a flush, recessed look instead of a surface mount.

Which American Dryer hand dryer models are compatible with the ADA-W Recess Kit?

It works with the GX Series, GXT9, EXT9, CPC9, and AD90 models only.

What components are included with the ADA-W Recess Kit?

The kit includes a stainless-steel wall box and a white epoxy face plate. The hand dryer is not included.

Is the ADA-W Recess Kit ADA-compliant?

Yes, it is designed to support ADA-compliant hand dryer installation in commercial restrooms.

What is the benefit of the white epoxy finish on the recess kit?

It resists rust and daily wear while giving the unit a clean look that blends well with most restroom walls.

Is the face plate included with the American Dryer ADA-W Recess Kit?

Yes, the face plate comes included along with the wall box.

Can I purchase replacement parts for the ADA-W Recess Kit?

Contact our support team to ask about available replacement parts for this kit.

Where can I buy the American Dryer ADA-W Recess Kit?

You can buy the American Dryer ADA-W Recess Kit directly from Allied Hand Dryer at handdryer.com.
